Double Eccentric Butterfly Valve with EPDM Seat Material and PN10 Pressure Rating Compliant with Drinking Water Standard

Product Description:

The Double Eccentric Butterfly Valve is a highly efficient and durable valve designed to regulate the flow of water in various industrial and commercial applications. Engineered with precision, this valve features a flange connection that ensures secure and reliable installation within piping systems. The use of flange connections not only provides ease of maintenance but also guarantees a tight seal, minimizing the risk of leaks and enhancing overall system integrity.

One of the standout features of this Double Eccentric Butterfly Valve is its seat material, which is made from high-quality EPDM (Ethylene Propylene Diene Monomer). EPDM is well-known for its excellent resistance to heat, ozone, and weathering, making it an ideal choice for water applications. This seat material ensures a tight seal against the valve disc, preventing any unwanted leakage and contributing to the valve’s longevity and reliable performance.

The valve is designed to operate efficiently across a temperature range of -10 to 80 degrees Celsius. This temperature range makes it suitable for a wide variety of water system applications, including potable water, wastewater treatment, and industrial water processes. The ability to function effectively within this temperature span ensures that the valve maintains its sealing performance and structural integrity under varying thermal conditions.

In terms of pressure handling capabilities, the Double Eccentric Butterfly Valve is rated for PN10, PN16, and PN25 pressures. This flexibility allows the valve to be used in different pressure environments, providing robust performance even under higher pressure conditions. The valve's design incorporates a double eccentric mechanism, which significantly reduces friction between the disc and seat during operation. This design feature not only extends the service life of the valve but also ensures smooth and reliable operation with minimal wear.

Another important characteristic of this valve is its compliance with recognized standards such as BS (British Standard) or ANSI (American National Standards Institute). Adherence to these standards guarantees that the valve meets rigorous quality, safety, and performance criteria, making it a dependable choice for engineers and system designers worldwide. The availability of valves manufactured according to these standards ensures compatibility with existing systems and regulatory requirements.

The Double Eccentric Butterfly Valve is designed with a bare head, which simplifies the installation and maintenance processes. The bare head design allows for easy access to the valve’s internal components without the need for extensive disassembly. This feature is particularly beneficial in applications where quick inspection and servicing are critical to maintaining uninterrupted system operation.

One of the notable operational advantages of this valve is its big torque capability. The double eccentric design reduces the torque required to open or close the valve, enabling smoother operation even in high-pressure conditions. This big torque feature translates into lower actuator power requirements and enhanced energy efficiency, making the valve an economical and environmentally friendly solution for water control systems.

Primarily used in water-related applications, this valve excels in controlling the flow and isolation of water in pipelines. It is widely employed in water treatment plants, irrigation systems, municipal water supply networks, and industrial water processing facilities. Its robust construction, reliable sealing, and ease of operation make it a preferred choice for operators seeking long-term performance and minimal maintenance.

In summary, the Double Eccentric Butterfly Valve with flange connection, EPDM seat material, and a temperature range of -10 to 80℃ is an excellent solution for water applications requiring reliable flow control under varying pressure conditions (PN10, PN16, PN25). Its bare head design facilitates easy maintenance, while compliance with BS or ANSI standards assures quality and compatibility. The big torque operation feature ensures smooth valve actuation, making this valve an indispensable component in modern water management systems.

Features:

• Product Name: Double Eccentric Butterfly Valve
• Connection Type: Flange
• Pressure Range: 0-2.5MPa
• Pressure Rating: PN10, PN16, PN25
• Standard Compliance: BS, ANSI
• Operation Methods: Manual, Gear, Electric
• Features EPDM Seal for enhanced sealing performance
• Durable Butterfly Valve design ensuring reliable flow control
• Double eccentric design reduces wear and extends valve life

Technical Parameters:

Applications:

The AFC Double Eccentric Butterfly Valve, available in models FBBD and FBGD, is designed to meet a wide range of industrial and commercial application needs. Manufactured in China, this valve is available in sizes ranging from 1 to 72 inches, making it highly versatile for different pipeline requirements. Its robust construction, featuring a steel disc ring and an EPDM seal, ensures excellent durability and leak-proof performance, even under varying pressure conditions.

One of the key application occasions for the AFC Double Eccentric Butterfly Valve is in water treatment plants, where reliable flow control and tight sealing are critical. The EPDM seat material is highly resistant to water and many chemicals, making it ideal for potable water systems and wastewater management. Additionally, the valve's temperature range of -10 to 80℃ allows it to operate effectively in both cold and moderately warm environments, broadening its usability across different climatic conditions.

In industrial settings such as HVAC systems and chemical processing plants, the valve’s double eccentric design minimizes wear on the sealing surface, thereby extending service life and reducing maintenance costs. The availability of valve worm gear operation options enhances precision and ease of control in large diameter installations, allowing operators to adjust flow with minimal effort. Furthermore, the valve can be operated manually, by gear, or electrically, providing flexibility depending on system automation requirements.

The AFC Double Eccentric Butterfly Valve is also suitable for use in fire protection systems due to its UL and FM certifications, ensuring compliance with stringent safety standards. Its reliable sealing capability, supported by the EPDM seal, prevents leakage and ensures system integrity during emergency situations.

Overall, this valve is perfect for pipelines requiring reliable fluid isolation and flow regulation across various industries including water distribution, HVAC, chemical processing, and fire protection. Its combination of a steel disc ring for enhanced strength, EPDM sealing for excellent chemical resistance, and valve worm gear available for precise actuation makes it a preferred choice for professionals seeking a high-quality, versatile butterfly valve solution.

Customization:

Our Double Eccentric Butterfly Valve, branded AFC and available in models FBBD and FBGD, offers exceptional performance for water applications. Manufactured in China with a durable ductile iron body, this valve is designed to handle pressure ratings of PN10, PN16, and PN25, ensuring reliable operation under various conditions. The valve meets international standards including BS and ANSI, guaranteeing quality and compatibility.

Featuring a double eccentric design, this butterfly valve provides a tight seal and reduces wear, enhancing longevity and efficiency. For applications requiring enhanced control and ease of operation, our valve worm gear is available as an optional accessory, allowing for precise valve positioning. Additionally, the valve delivers big torque performance, making it suitable for demanding industrial environments.

The valve connection is flange type, ensuring easy installation and compatibility with existing piping systems. Choose AFC's Double Eccentric Butterfly Valve for a robust, high-quality solution tailored to your water system needs.

Support and Services:

Our Double Eccentric Butterfly Valve is designed to provide reliable performance in a wide range of industrial applications. For technical support, our team of experts is available to assist with installation guidance, troubleshooting, maintenance tips, and operational advice to ensure optimal functionality and longevity of the valve.

We offer comprehensive services including valve inspection, testing, repair, and refurbishment. Our support includes detailed documentation and user manuals to help you understand the specifications and correct usage of the valve.

Additionally, we provide customized solutions tailored to specific project requirements, ensuring compatibility and efficiency within your system. Our commitment is to deliver prompt and effective support to minimize downtime and maximize productivity.

For ongoing maintenance, we recommend regular inspection of the valve components, lubrication of moving parts, and timely replacement of seals to prevent leaks and maintain tight shut-off performance.

Trust our technical support and services to keep your Double Eccentric Butterfly Valve operating at peak performance throughout its service life.
