Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System

Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System

  • Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System
  • Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System
  • Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System
  • Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System
Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System
Product Details:
Place of Origin: China
Brand Name: AFC OEM
Certification: WRAS, NSF61/372
Model Number: NSCV
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD RMB
Packaging Details: Plywood cases
Delivery Time: 45-60 days
Payment Terms: L/C, T/T
Supply Ability: Based on order
Contact Now
Detailed Product Description
Material: Ductile Iron GJS500-7 Standard: EN1074-3, EN12233
Fuction: Anti Water Hammer Coating: EPOXY
Color: Blue Head Loss: Low
Highlight:

non slam type check valve

,

anti water hammer check valve





Low Head Loss Anti Water Hammer Non Slam Check Valve EPOXY Coated Quick Close Ductile iron







Description



NSCV- Non Slam Check Valve is used as protection against reverse flow when power failure in areas where noise pollution or water hammering is a critical issue. It can provide not only quiet performance but also low head loss.



Features:



·High strength ductile iron body used for durability and less weight.
·Advanced dynamic design of single body with diffuser provides streamline flow and assures lower head loss.
·One of the lowest head loss check valve, big save in pumping power cost, valve disc with shorter stroker and spring reverse faster than most of check valve.
·Coated with powder epoxy both inside & outside for corrosion resistance.
·Bronze bushing reduce wearing problem during operation.
·Hydrodynamic design with spring ensures non slamming and water hammerless.
·Stainless steel spring hidden in the diffuser under protection while valve in operation.
·Disc will positively close before reverse flow, and maximize the closing speed up to 0.2 Sec.
· Installation can be vertical/horizontal/inclined.
·Comply with EN 558-1, ISO 5752 and EN 1092-2, ISO 7005-2 flange dimension.



Technical Data:



Size DN50-DN600
Working Temperature - 10C- 80C
Flange AISI B16.1 Or PN16
Flow Media Clean Water



Service Fields:


Mainly used for clean water, precleaned sewage water, Fire-fighting, Irrigation, Cooling and HVAC System.





Dimension:



DN50 - DN350

Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 0



Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 1



DN400 - DN600

Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 2

Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 3





Materials:



DN50-DN350

Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 4Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 5



Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 6Hydrodynamic Design Water Hammer Prevention Check Valve For Cooling System / HVAC System 7
