ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection

ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection

  • ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection
  • ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection
  • ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection
  • ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection
ANSI B16.1 End Flange Fire Fighting System With Flanged / Grooved Connection
Product Details:
Place of Origin: China
Brand Name: AFC
Model Number: FRHF, FNCF, FRHG, FNCG
Contact Now
Detailed Product Description
Size: 2”-12” Material: Ductile Iron
Standard: ANSI/UL/FM Design: UL/FM
Seal: EPDM Temperature: -10℃-80℃
Painting: Fusion Bonded Epoxy Coating End Flange: ANSI B16.1
Highlight:

Flanged Connection Fire Fighting System

,

ANSI B16.1 Fire Fighting System

,

Fire Fighting UL FM Approved Valves

Product Description:

UL FM Gate Valve is a reliable and highly efficient solution for a wide range of industrial water applications. It is made of durable ductile iron and coated with red epoxy for superior corrosion resistance. It is UL and FM approved for use in Class 125 and 150 pressure systems, and has a face to face dimension compliant with ANSI B16.10. This gate valve is designed to withstand temperatures ranging from -10℃ to 80℃, making it suitable for a wide variety of water systems. With its superior design and materials, UL FM Gate Valve ensures reliable and safe operation for years to come.



Features:

  • Product Name: UL FM Gate Valve
  • Standard: ANSI/UL/FM
  • Temperature: -10℃-80℃
  • Operation: Handwheel/Cap
  • Design: UL/FM
  • Material: Ductile Iron
  • Features:For fire fighting system
  • Type: Flange Or Groove Type Non Rising Stem Resilient Seated Valve
  • Optional: Flange Or Groove Type Non Rising Stem Resilient Seated Valve with Bypass


Technical Parameters:

Attribute Value
Pressure Class125/150
Temperature -10℃-80℃
Standard ANSI/UL/FM
Face to Face ANSI B16.10
Size 2”-12”
Painting Fusion Bonded Epoxy Coating
Seal EPDM
Certificate UL/FM
Operation Handwheel/Cap
Material Ductile Iron
Flange Or Groove Type Non Rising Stem Resilient Seated Valve
Approved UL FM
Usage For fire fighting system


Applications:

AFC UL FM Gate Valve is the ideal choice for fire fighting system. It is made of high quality ductile iron material, which is resistant to corrosion and erosion. It is approved by UL FM, and available in flange or groove type non rising stem resilient seated design. Its pressure rating is Class125/150 according to ANSI B16.1. It is suitable for temperature ranging from -10℃-80℃. The available size includes 2”-12”. The model number is FRHF, FNCF, FRHG and FNCG.



Customization:

  • Brand Name: AFC
  • Model Number: FRHF, FNCF, FRHG, FNCG
  • Place of Origin: China
  • Operation: Handwheel/Cap
  • Standard: ANSI/UL/FM
  • Face to Face: ANSI B16.10
  • Certificate: UL/FM
  • End Flange: ANSI B16.1
  • Special Features: Red Epoxy Coated, UL FM Approved Water Gate Valve, UL FM Approved Fire Gate Valve


Support and Services:

  • Technical Support: UL FM Gate Valve products are provided with comprehensive technical support. Our team of experienced and knowledgeable engineers are available to answer any technical questions you may have. Additionally, our website contains frequently asked questions and detailed installation guides.
  • Service: We are committed to providing our customers with exceptional service. Our customer service team is available to assist with product selection, product installation, troubleshooting, and product maintenance.


Packing and Shipping:

Packaging and Shipping of UL FM Gate Valve:

The UL FM Gate Valve shall be packaged in export-standard wooden cases/plywood cases and shipped to the designated place.



FAQ:

  • Q: What is UL FM Gate Valve?
    A: UL FM Gate Valve is a kind of gate valve which is certified by UL and FM.
  • Q: What are the brand name and model numbers of UL FM Gate Valve?
    A: Brand Name: AFC, Model Numbers: FRHF, FNCF, FRHG, FNCG.
  • Q: What material is UL FM Gate Valve made of?
    A: UL FM Gate Valve is made of high quality ductile iron.
  • Q: Where is UL FM Gate Valve produced?
    A: UL FM Gate Valve is produced in China.
  • Q: What is the temperature range of UL FM Gate Valve?
    A: UL FM Gate Valve can withstand temperature range from -20℃ to 120℃.
